EX3600-7

With its renowned design and innovative features, Hitachi’s EX3600-7 large excavator has emerged from a long line of predecessors to become the best model of its class on the market. Mining operations with the EX3600-7 benefit from maximised efficiency, assured durability, and a seamless operator experience.

Potenza nominale del motore (kW): 1,450 (1,971 PS)/MTU: 1,450 (1,971 PS)
Peso operativo (kg): 365 000 - 366 000 kg
Benne ISO a colmo: 22 m³
Disponibile in: Europe

With its renowned design and innovative features, Hitachi’s EX3600-7 large excavator has emerged from a long line of predecessors to become the best model of its class on the market. Mining operations with the EX3600-7 benefit from maximised efficiency, assured durability, and a seamless operator experience.

Richiesta preventivo
Ricerca Concessionario
Compara Modello
Overview
About the EX3600-7

The EX3600-7 has been built to withstand the harshest mining conditions while delivering outstanding productivity and exceptional around-the-clock performance. Operators also benefit from complete comfort, thanks to enhanced features in the cab, such as advanced air suspension seating and improved climate control.

Benefits
Discover the benefits
  • Superior productivity under different digging profiles.
  • Hitachi’s energy optimisation technologies are kinder to the planet and reduce consumption costs.
  • Easier and safer to maintain than ever before with an intuitive design.
  • Low vibration levels in the cab results in a more comfortable working environment.
Download Brochure
Specifications

Specifications for the EX3600-7 Excavator

Espandi tutto Comprimi tutto
  • Motore e sistema idraulico
Modello Cummins QSKTA60-CE (FCO, T4F/EU Stage V)
Potenza nominale ISO 14396 1 450 kW (1 971 PS, 1 944 HP)
Cilindrata del pistone 60 L
Pompe principali 8 variable-displacement, axial piston pumps for front attachment, travel and swing
Impostazione della pressione 29.4 MPa (300 kgf/cm2, 4 264 psi)
Portata massima dell’olio 6 X 335 L/min
  • Allegati
Caricamento della pala ISO 7546 accumulato 2 22.0 m3 (28.8 cu. yd.) : Material density
Caricamento della pala ISO 7546 accumulato 2 24.0 m3 (31.4 cu. yd.) : Material density
Backhoe ISO 7451 2007 22.0 m3 (28.8 cu. yd.) : Material density
Backhoe ISO 7451 2007 24.0 m3 (31.4 cu. yd.) : Material density
  • Peso operativo e pressione al suolo (Caricamento della pala)
Tipo di pattini Loading Shovel
Larghezza 1 270 mm (50 in.)
Peso operativo 369 000 kg (813,506 lb.)
Pressione al suolo 193 kPa (1.97 kgf/cm3, 28 psi)
  • Peso operativo e pressione al suolo (Backhoe)
Tipo di pattini Backhoe
Larghezza 1 270 mm (50 in.)
Peso operativo 370 000 kg (815,710 lb.)
Pressione al suolo 194 kPa (1.98 kgf/cm , 28.1 psi)
  • Raggi operative
Lunghezza braccio di penetrazione 4.5 m
Sbraccio max. 18 240 mm
Max. profondità di scavo 8 630 mm
Max. altezza di scarico 11 540 mm
  • Lunghezza sottocarro
Larghezza sottocarro 8 700 mm
Larghezza complessiva torretta 9 420 mm
  • Specifiche
Potenza nominale del motore (kW) 1,450 (1,971 PS)/MTU: 1,450 (1,971 PS)
Peso operativo (kg) 365 000 - 366 000 kg
Benne ISO a colmo 22 m³
Benne ISO a colmo 8 630 mm
Download Brochure
Attachments
Attachments enhance the versatility of your EX3600-7
  • Durable hydraulic breakers, buckets and ground engaging tools will increase your profit by maximising productivity and uptime.
  • Choose from a wide range of Hitachi buckets to suit the application. Quick coupler connections are also available.
  • Hitachi-approved breakers are easy to maintain, user-friendly, and high-quality materials ensure a long lifetime.
  • Hitachi ground engaging tools (GET) fit precisely to your attachments, and are quick and safe to install and replace.
Download Brochure
