About the EX5600-7

Designed for sustainability The Hitachi EX-7 series utilizes the latest advancements in engine and energy optimization technologies to deliver a customized and sustainable machine, while providing a significant reduction in fuel consumption without compromising productivity. The EX5600-7 offers a selection of engine models, including the choice of emission configurations to meet regulatory requirements, combined with new electronically controlled hydraulic pumps, optimized cooling package and enhanced hydraulic circuits, to provide unparalleled performance and efficiency. Designed for productivity Engineered from the ground up with advanced technologies to maximize productivity, the EX5600-7 delivers a reliable solution for all operations. Embracing the Hitachi design philosophy of balanced reliability and productivity, the EX5600-7 optimizes machine performance, providing a consistent and dependable solution to meet the demands of the mining industry.

Benefits
Discover the benefits
  • Exceptional fuel efficiency.
  • Reduced life-cycle costs and less environmental impact.
  • Integrated remote operation system, operation support system and autonomous operation function.
Specifications

Specifications for the EX5600-7 Excavator

Espandi tutto Comprimi tutto
  • Motore e sistema idraulico
Modello Cummins QSKTA50-CE (FCO, T4F/EU Stage V)
Potenza nominale ISO 14396 2 x 1 119 kW (1 520 PS, 1 500 HP)
Cilindrata del pistone 2 x 57.2 L (2 x 3,491 cu. in.)
Pompe principali 12 variable-displacement, axial piston pumps for front attachment, travel and swing
Portata massima dell’olio 8 x 375 L/min (8 x 99.1 gal/min), 4 x 425 L/min (4 x 112.3 gal/min)
  • Allegati
Capacità del secchio (ISO annebbato) 27.0 m3 (35.3 cu. yd.) : Material density 1 800 kg/m3 (3,034 lb./cu. yd.) or less
Capacità del secchio (ISO annebbato) 29.0 m3 (38 cu. yd.) : Material density 1 800 kg/m3 (3,034 lb./cu. yd.) or less
Capacità del secchio (ISO annebbato) 31.5 m3 (40.5 cu. yd.) : Material density 1 600 kg/m3 (2,697 lb./cu. yd.) or less
Capacità del secchio (ISO annebbato) 34.0 m3 (44.5 cu. yd.) : Material density 1 800 kg/m3 (3,034 lb./cu. yd.) or less
Capacità del secchio (ISO annebbato) 36.0 m3 (47.1 cu. yd.) : Material density 1 800 kg/m3 (3,034 lb./cu. yd.) or less
Capacità del secchio (ISO annebbato) 38.5 m3 (50.4 cu. yd.): Material density 1 600 kg/m3 (2,697 lb./cu. yd.) or less
  • Peso operativo e pressione al suolo (Caricamento della pala)
Tipo di pattini Loading Shovel
Larghezza 1 400 mm
Peso operativo 544 000 kg
Pressione al suolo 244 kPa (2.51 kgf/cm2, 35.4 psi)
  • Peso operativo e pressione al suolo (Backhoe)
Tipo di pattini Backhoe
Larghezza 1 400 mm
Peso operativo 549 000 kg
Pressione al suolo 246 kPa (2.51 kgf/cm2, 35.7 psi)
  • Raggi operative
Max. Scaving Force 9K 1 590 kN
Max. altezza di scarico 8900 mm
Max. profondità di scavo 4 800
  • Lunghezza sottocarro
Larghezza sottocarro 7 400 mm
Larghezza complessiva torretta 10 300 mm
  • Specifiche
Potenza nominale del motore (kW) 2 x 1 119 kW (1 520 PS, 1 500 HP
Peso operativo (kg) 541 000 - 553 000 kg
Benne ISO a colmo 34.0 m³
Max. profondità di scavo (mm) 4 800
Attachments
Attachments enhance the versatility of your EX5600-7
  • Durable hydraulic breakers, buckets and ground engaging tools will increase your profit by maximising productivity and uptime.
  • Choose from a wide range of Hitachi buckets to suit the application. Quick coupler connections are also available.
  • Hitachi-approved breakers are easy to maintain, user-friendly, and high-quality materials ensure a long lifetime.
  • Hitachi ground engaging tools (GET) fit precisely to your attachments, and are quick and safe to install and replace.
