About the EX2600-7E

Designed for productivity Mining is a very demanding industry, which is why Hitachi’s EX-7 excavators go above and beyond project requirements to deliver maximum performance. The EX2600-7 is packed with efficient features to meet any challenge. Operator comfort A comfortable operating environment is essential for productivity, and the EX2600-7 is engineered for a luxurious operator experience. Features like ergonomic layout, electronic joysticks, intelligent Multi-Functional Display, advanced air suspension seating and better climate control boost operator productivity.

Benefits
Discover the benefits
  • Exceptional fuel efficiency.
  • Reduced life-cycle costs and less environmental impact.
  • Integrated remote operation system, operation support system and autonomous operation function.
Specifications

Specifications for the EX2600-7E Excavator

Expand all Collapse all
  • Engine & hydraulic system
Main pumps 6 variable-displacement, axial piston pumps for front attachment, travel and swing
Maximum oil flow 4 x 375 L/min (4 x 99.1 gal./min.), 2 x 425 L/min (2 x 112.3 gal./min.)
  • Attachments
Bucket Capacity (ISO 7546 Heaped 2 1) Loding Shovel 15.0 m3 (19.6 cu.yd.) : Material density 1 800 kg/m3 (3,034lb./cu.yd.) or less
Bucket Capacity (ISO 7546 Heaped 2 1) Loding Shovel 16.5 m3 (21.6 cu yd.): Material density 1 600 kg/m3 (2,697lb./cu.yd.) or less
Bucket Capacity (ISO Heaped) Backhoe (ISO 751:2007 Heaped 1:1) 17.0 m3 (22.2 cu.yd.): Material density 1 800 kg/m3 (3.034 lb./cu.yd.) or less
Bucket Capacity (ISO Heaped) Backhoe (ISO 751:2007 Heaped 1:1) 18.0 m3 (23.5 cu.yd.): Material density 1 800 kg/m3 (3.034 lb./cu.yd.) or less
Bucket Capacity (ISO Heaped) Backhoe (ISO 751:2007 Heaped 1:1) 19.0 m3 (25.5 cu.yd.): Material density 1 600 kg/m3 (2.697 lb./cu.yd.) or less
  • Weights and Ground pressure (Loading Shovel)
Shoe type Induction-Hardened Cast Steel
Shoe width 1 000 mm (40 in.)
Operating weight 259 000 kg (570,997 lb.)
Ground pressure 189 kPa (1.92 kgf/cm2, 27.4 psi)
  • Weights and Ground pressure (Backhoe)
Shoe type Induction-Hardened Cast Steel
Shoe width 1 000 mm (40 in.)
Operating weight 257 000 kg (566,588 lb.)
Ground pressure 187 kPa (1.91 kgf/cm2, 27.1 psi)
  • Working ranges
Max. digging reach Loading Shovel 14 060 mm (46 ft. 2 in.)
Max. dumping height Loading Shovel 10 350 mm (34 ft.)
Max. digging reach Backhoe 16 600 mm (54 ft. 6 in.)
Max. digging depth Backhoe 8 250 mm (27 ft. 1 in.)
Max. dumping height Backhoe 10 100 mm (33 ft. 2 in.)
  • Dimensions
Undercarriage width 6 000 mm (19 ft. 8 in.)
Overall width of upper structure 8 040 mm (26 ft. 5 in.)
  • Specifications
Bucket capacity (m³) ISO Heaped [Loading Shovel: ISO 7546 Heaped 2:1] : 15.0 - 16.5 m3 (19.6 - 21.6 cu. yd.) / [Backhoe: ISO 7451:2007] : 17.0 - 19.5 m3 (22.2 - 25.5 cu. yd.)
Attachments
Attachments enhance the versatility of your EX2600-7E
  • Durable hydraulic breakers, buckets and ground engaging tools will increase your profit by maximising productivity and uptime.
  • Choose from a wide range of Hitachi buckets to suit the application. Quick coupler connections are also available.
  • Hitachi-approved breakers are easy to maintain, user-friendly, and high-quality materials ensure a long lifetime.
  • Hitachi ground engaging tools (GET) fit precisely to your attachments, and are quick and safe to install and replace.
